EN
23
Oven Light
When replacing the oven light, make sure that you are
wearing gloves to avoid injury from the heat of the lamp.
1. Unplug the oven or turn off the power at the main power
supply.
2. Remove the vent grille mounting 3 screws and open the
door.
3. Slide the grille air to the left, then pull it straight out.
4. Remove the charcoal filter, if present.
5. Pull the hook a little and remove light cover.
6. Push the right hook holding the oven light to the right
side and remove the LED light.
7. Replace with 0.4-watt LED light available from your
authorized dealer.
8. Replace the light cover.
9. Replace the grille air and 3 screws and close the door.
10. Plug the oven in or turn on the power at the main power
supply.
LIGHT COVER LED LIGHT
Install/Replace Charcoal Filter
Charcoal Filter
If your oven is vented to the inside, the charcoal filter should
be replaced if it is used for approximately 6 months.
You can purchase Charcoal Filter from Fulgor Milano.
1. Unplug the oven or turn off the power at the main power
supply.
2. Remove the grille air mounting 3 screws and open the
door.
3. Slide the grille air to the left, then pull it straight out.
4. Push the charcoal filter backward and remove it.
5. Slide a new charcoal filter into place. The filter should
rest at the angle.
6. Replace the grille air and 3 screws and close the door.
7. Plug the oven in or turn on the power at the main power
supply.
CHARCOAL FILTER GRILLE AIR
7 - CARE AND CLEANING
