CSVEQ 100 D • Installation
Installation
2-2
Application Example
To get started, refer to the "Quick Start Guide" at the beginning
of this manual.
C Installation and service must be performed by
authorized personnel only.
- AUDIO IN - L
R
S-VIDEO IN
VIDEO IN
DVD/VCR
Combo
Extron
MPA 122
Mini Power
Amplifier
Extron
SI 26X
Two-way Ceiling
Speakers
Extron
CSVEQ 100 D
Composite Video, S-Video,
and Audio Line Driver
S-Video
Composite
Video
1,000 Feet
Projector
Balanced
Audio
CSVEQ 100 D application example
