Water Connections
Liebert
®
CRV
™
34
Table 19
Unit connections, water/glycol-cooled models
Unit Connections
CR20W (50Hz)
CR35W (50Hz)
CR20W (60Hz)
CR35W (60Hz)
CS
Water/Glycol Coolant Supply
32mm GAS F
1-1/4" FPT
CR
Water/Glycol Coolant Return
32mm GAS F
1-1/4" FPT
GD
Gravity Coil Pan Drain
20mm I.D.
1" MPT
GDH Gravity Humidifier Drain
22mm I.D.
N/A
HS
Humidifier Supply
1/2" GAS F (top connection)
3/4" GAS F (bottom connection)
1/2" FPT (top connection)
1/4" Compression Fitting
(bottom connection)
CP
Condensate Pump
1/2" GAS F
1/2" FPT
HVT High Voltage Top Connection
Combination Knockout Hole
Diameter 1-3/8" (35mm)
1-3/4" (44.5mm) and 2-1/2" (63.5mm)
Combination Knockout Hole
Diameter 1-3/8" (35mm)
1-3/4" (44.5mm) and 2-1/2" (63.5mm)
HVB High Voltage Bottom Entrance
(feed through the base of the unit)
Hole Diameter 2-1/2" (63.5mm)
Knockout Hole Diameter 2-1/2" (63.5mm)
LVT Low Voltage Top Connection
Hole Diameter
7/8" (22mm) 2 places
Knockout Hole Diameter
7/8" (22mm) 2 places
LVB Low Voltage Bottom Entrance
(feed through the base of the unit)
Hole Diameter 1-7/64" (28mm)
2 places
Knockout Hole Diameter
1-3/32" (27.8mm) 2 places
LVB2 Low Voltage Bottom Entrance
(feed through the base of the unit)
—
Knockout Hole Diameter
1-3/4" (44.5mm) 1 place
Source: DPN001793, Rev. 2
