English

1: Pixel-Repetition signal (dot clock frequency 27.0 MHz) only

2: Signals to represent formats are as follows.

R : D-sub RGB (PC IN)
H : HDMI (HDMI IN 1, HDMI IN 2, HDMI IN 3)

3: Based on VESA CVT-RB (Reduced Blanking) standard

4: Signals with ○ in the Plug and Play-supported signal column are the ones written in EDID (Extended Display

Identification Data) of this unit.
For signals without ○ in the Plug and Play-supported signal column, resolutions may not be selected on the PC

side even if this unit supports those signals.

Note

●

An auto detected signal format may be differently displayed from the actual input signal.

●

[ i ] shown after the number of dots of resolution means the interlace signal.
