38
English
Position
Adjusts the position.
[Position] - submenu screen
Note
● In some cases, noise appears outside the area
picture is displayed, but it is not a malfunction of the
image.
● It is only available for PC input.
[Position] - submenu screen
Auto setup
Dot clock 50
Clock phase 75
H-position 50
V-position 50
Reset
Position
■
[Auto setup]
Sets the operational mode of the automatic position
adjustment.
Note
● [Auto setup] may not work when a cropped or dark
image is input. In such case, switch to a bright
image with borders and other objects are clearly
shown, and then try [Auto setup] again.
■
[Dot clock]
Periodic striped pattern interference (noise) may
occur when a striped pattern is displayed. If this
happens, adjust so that any such noise is minimized.
■
[Clock phase]
Adjusts sampling clock for applicable video.
Useful when small characters appear with low
contrast and/or there are flickers at corners.
When using the adjustment pattern, make
adjustments so that no horizontal stripe noise
appears in it.
● It should be made only after [Dot clock] has been
correctly set.
■
[H-position]
Adjusts the horizontal position of the image.
■
[V-position]
Adjusts the vertical position of the image.
■
[Reset]
Resets the values of [Position] items to the factory
default settings.
Note
● In some cases, noise appears outside the area
picture is displayed, but it is not a malfunction.
● It is only available for PC input.
● In the case that [Auto setup] cannot work well,
[Auto setup] may work well to execute [Reset]
before [Auto setup].
Power save mode
When this function is set to [Disable], the power can
be turned on by LAN control in standby mode, but the
power consumption is increased in standby mode.
When this function is set to [Enable], the power cannot
be turned on by LAN control in standby mode, but the
power consumption is reduced in standby mode.
(Serial control enables the power to be turned on
in standby mode regardless of [Disable] or [Enable]
selected in the setting.)
Power Management
This function turns the power off (standby) when video
signals are not detected with HDMI or PC input, and
turns the power on when video signals are detected.
Note
● If the power is turned off (standby) using the remote
control, this function is not activated.
● Video signals can be detected only with input
terminals with which video signals are not detected at
power-on. When the unit enters the standby state with
this function, the power indicator lights in orange.
e.g. When video signals are not detected with HDMI1
input:
Power off (standby), Power indicator lights in
orange.
When video signals are detected with HDMI1
input later:
Power on, Power indicator lights in green.
