Bottom Logo
There is a dead corner at the bottom (nadir) of the panorama photo/video, which is usually covered with a blend
transition or with a logo image.
The Pilot can adjust the proportion of the Logo relative to the overall image. Minimum 4%, maximum 30%. The
larger the logo, the larger the area covering the bottom. If the Logo ratio is
x
% and the center of the Pilot lens is
h meters from the ground, the formula is as follows:
Logo coverage length = tan ( π * x / 100 ) * h * 2 1
Pilot can choose whether to use the Logo image to cover the bottom dead corner, you can use your own Logo
image to cover the bottom.
First, connect the Pilot to your computer. Copy your Logo images to the
Pilot Era/Watermarks/
directory. Then
open Pilot, Settings - Bottom Logo , the logo image will be displayed in the UI. Select one, then
shoot/record/live, The resulting image will use the new bottom logo.
