RF-Links 1000mW Wideband Microwave Amplifier (50 MHz–6 GHz) - Manual (Page 2)

Typical Performance at Key Operating Frequencies (0.5GHz to 3.5GHz Application Circuit)
Specification
Parameter
Min. Typ. Max.
Unit Condition
35 dB 50 MHz
34 dB 100 MHz
33 dB 200 MHz
36 dB 500 MHz
33 dB 850 MHz
2 dB 1950 MHz
30 dB 2500 MHz
28 dB 3500 MHz
27 dB 4000 MHz
Small Signal Gain
25 6000 MHz
42 dBm 50 MHz
44 dBm 100 MHz
42 dBm 200 MHz
43 dBm 500 MHz
44 dBm 850 MHz
44 dBm 1950 MHz
32.8 dBm 2500 MHz
39 dBm 3500 MHz
38 dBm 4000 MHz
Output Third Order Intercept Point
37 6000 MHz
29.5 dBm 50 MHz
33 dBm 100 MHz
32 dBm 200 MHz
32 dBm 500 MHz
28 dBm 850 MHz
26 dBm 1950 MHz
24 dBm 2500 MHz
24 dBm 3500 MHz
24 dBm 4000 MHz
Output Power at 1dB Compression
23 6000 MHz
