RF-Links High-Power 7W Wideband Amplifier (400-470 MHz) User Manual
Page 2
AMPLIFIER ZH4047/7
Frequency
MHz
GAIN, dB
Maximum
Power, dBm
Dynamic
Range
DC POWER
f
L
- f
U
Min.
Max.
Flatness
Max
.
Input
(no
damage)
NF
Db
Typ.
IP3
dBm
Typ.
Cur-
rent(m
A)
Volt(V.)
400-470
26 ±0.80 +34.8 +15 3.7 46 1.9 12
Lw = low range(fL to fU/2) U=upper range(fU/2 to fU)
Gain (dB)
Directivity
(dB)
VSWR
N.F.(dB)
Pout mW
(@1dB
COMPR
FREQ (MHz)
12 V
12V
IN
OUT
400
26
10.5
1.29
1.30
4.08
7200
420
27
11.1
1.63
1.65
3.99
7350
430
27
11.6
1.66
1.69
3.99
7244
440
26.5
11.3
1.38
1.42
3.82
7800
450
26.8
11.4
1.16
1.19
3.95
7899
460
26
11.9
1.20
1.20
3.95
7788
470
26
13.4
1.16
1.31
3.84
8200
475
26
13.1
1.17
1.23
3.92
7988
480
26
13.7
1.29
1.23
3.86
7458
