Mil grade high power amplifier – RF-Links Military-Grade 200W High-Power Amplifier (800 MHz to 2.5 GHz) User Manual
Page 2
ZHM800-2500/200
MIL Grade High Power Amplifier
Copyright © 2001-2015 RF-LINKS
Current consumption @ RF OFF – Pin 5
I
RF_OFF
1.5 Amp
RF ON/OFF
Switching Time @ 100KHz TTL, P
IN
= 0dBm
T
ON/OFF
1.0
us
Mute Control
Switching Time @ 1KHz TTL, P
IN
= 0dBm
T
ON/OFF
2.0 5.0 us
Mechanical Specifications
PARAMETER
VALUE
UNITS
LIMITS
Dimensions
3.5” X 7.5” X 1.0”
Inch
Max
Weight
1.0
lb
Max
RF Connectors In/Out
SMA Female
DC Connectors
Cooling
External Heatsink (Not
Supplied)
