Settings
6
Attaching the BT-1 to a Stand
In order to attach the BT-1 to a stand (rod type mount), you must first install the included
attachment on the BT-1.
Installing the attachment
1.
Install the attachment on the BT-1 as shown in the illustration.
Use the included attachment bolts to fasten the attachment securely.
* Remove the spacer.
* Use your own drum key to tighten the bolts.
Attaching the BT-1 to a stand
1.
Attach the BT-1 to the rod of the stand, and tighten the stand attachment bolt.
* When attaching the BT-1 to the stand, be sure to tighten the stand attachment bolt securely. If
any of them remain loose, the pad could fall off.
MEMO
When attaching the BT-1 to a commercially available rod type mount, check the dimensions of
the rod. Depending on the dimensions of the rod, it may not be possible to attach the pad to
the rod.
Acceptable rod diameters: 8.0–12.5 mm (3/8–1/2 inch)
Drum Key
Tighten Loosen
Attachment
Bolts
Stand attachment bolt
