Page 30 AN-X-MOD (Master) November 2011
To map the module status data for a given Quantum drop, include a line
with the keyword dnModSts, where n is the drop number, from 1 to 32,
in the input section of a connection.
Examples:
,d4ModSts
30, d4ModSts ; offset 30
Connection Statistics
The module maintains statistics for each exclusive owner scheduled
connection. In the following table, O represents the connection
originator (ControlLogix) and T represents the connection target
(AN-X).
There are 10 words of data for the connection:
Offset Description
0 Average time for last 100 CLX to AN-X updates
1 Minimum time for last 100 CLX to AN-X updates
2 Maximum time for last 100 CLX to AN-X updates
3 Maximum CLX to AN-X time since connection opened
4 Reserved
5 Average time for last 100 AN-X to CLX updates
6 Minimum time for last 100 AN-X to CLX updates
7 Maximum time for last 100 AN-X to CLX updates
8 Maximum AN-X to CLX time since connection opened
9 Reserved
The units for the times are 0.1 milliseconds. A value of 87 means 8.7
ms.
To map the statistics for a given connection, include a line with the
keyword ConnStatsn, where n is the connection number, from 0 to 15, in
the input section of a connection.
Examples:
, ConnStats2
40, ConnStats2 ; offset 40
