116 Using the Printer Software with Macintosh
R4CE640
long.bk
Rev. E
A5 size DMNH.FM
6/10/04
L Proof Sign-off:
ABE J.Hashimoto, K.Iwamura
M.Ishigami
S. Halvorson
a. Icon/Message: The icon and message shows the
printer status.
b. Printer image: The image at the upper left
shows the printer status
graphically.
c. Text box: The text box next to the printer
image displays the current status
of the printer. When a problem
occurs, the most probable
solution is displayed.
d. Close button: Clicking this button closes the
dialog box.
e. Paper: Displays the paper size, the
paper type and the approximate
amount of paper remaining in
the paper source. Information for
the optional cassettes are
displayed only if this option is
installed.
f. Toner: Indicates the amount of
remaining toner. The toner icon
flashes if toner is low.
g. Photoconductor Unit: Indicates the remaining
functional life of the
photoconductor unit.
