DMIIIS
EN - 18
CO-GENERATION
ON = the instrument is able to face situations of CO-
GENERATION of electrical equipment (that is, the
equipment under test is able to generate energy besides
absorbing it). Accordingly, the instrument will record the
powers and energies both absorbed and generated (see
paragraph 16.3.1). If this flag is enabled the maximum
number of parameters which can be selected decrease
to 38.
OFF = the instrument will record ONLY the powers and
energies absorbed.

Pt, P1, P2, P3,
P12, P32
Values of the active power (total, of phase1, phase2 and phase3)
(only for 3 wires measurement) value of the power measured
by the Wattmeter 1-2 and 3-2 respectively

Single phase: P1
3 wires: Pt
4 wires Pt, P1, P2, P3
Qti, Q1i, Q2i, Q3i,
Q12i, Q32i
Values of the inductive reactive power (total, of phase 1,
phase 2, phase 3)
(only for 3 wires measurement) value of the reactive inductive
power measured by the VAR meters 1-2 and 3-2 respectively

Single phase: Q1i Q1c
3 wires: Qti Qtc
4 wires Qti Q1i Q2i,
Q3i
Qtc Q1c Q2c, Q3c
Qtc, Q1c, Q2c, Q3c,
Q12c, Q32c
Values of the capacitive reactive power (total, of phase 1,
phase 2, phase 3)
(only for 3 wires measurement) value of the reactive capacitive
power measured by the VA meters 1-2 and 3-2 respectively
St, S1, S2, S3, S12,
S32
Values of the apparent power (total, of phase1, phase2,
phase3)
(only for 3 wires measurement) value of the power measured
by the VA meters 1-2 and 3-2 respectively

Single phase: S1
3 wires: St
4 wires St, S1, S2, S3
Pft, Pf1, Pf2, Pf3
Values of the power factors (total, of phase 1, phase 2 and
phase 3 respectively) 
Single phase: Pf1 dPf1
3w: Pft dPft
4w: Pft Pf1 Pf2 Pf3
dPft dPf1 dPf2 dPf3
dpft, dpf1, dpf2, dpf3
Values of the cos

(total, of phase 1, phase 2 and phase 3
respectively)
Eat, Ea1, Ea2, Ea3
Values of the active energy (total, of phase1, phase2 and
phase3)

Single phase: Ea1
3 wires: Eat
4 wires Eat Ea1 Ea2
Ea3
Erit, Eri1, Eri2, Eri3
Values of the inductive reactive energy (total, of phase 1,
phase 2 and phase 3) 
Single phase: Eri1
Erc1
3 wires: Erit Erct
4 wires Erit Eri1 Eri2
Eri3 Erct Erc1 Erc2
Erc3
Erct, Erc1, Erc2, Erc3
Values of the capacitive reactive energy (total, of phase 1,
phase 2, phase 3)
Est, Es1, Es2, Es3
Values of the Apparent Energy (total, of phase1, phase2 and
phase3)

Single phase: Es1
3 wires: Est
4 wires Est Es1 Es2
Es3
The value of the network frequency is automatically selected if at least one phase voltage (for the
single-phase mode or the 4 wires three phase mode) or at least one phase-to-phase voltage (for the 3
wires three phase mode) is selected.
The symbols "i" and "c" stand for reactive powers (Q), power factors (Pf) and cos

(dpf) inductive and
capacitive respectively.
Selecting a power factor (Pf) or a cos

(dPf) for the recording automatically their inductive value and their
capacitive value will be recorded separately.
For eventual messages displayed see appendix 1
– MESSAGES DISPLAYED.
