Amprobe DM-111S Current-Data-Logger User Manual
Page 15
DMIIIS
EN - 13
1
st
Page of the RECORDER
CONFIG MENU
Example of 2
nd
page in single-
phase mode with ANOM flag
enabled
Example of 2
nd
page in “3
wires” three-phase mode with
ANOM flag enabled
Example of 2
nd
page in “4 wires”
three-phase mode with ANOM
flag enabled
Example of sub-page
"VOLTAGE HARMONICS"
RECORDER CONFIG
START
MANU
STOP
MANU
INT. PERIOD: 15min
HARM REC: ON
ANOM REC: ON
+
-
RECORDER CONFIG
VOLTAGE:
V1
HARM. REC:Pg (ON)
Vref P-N: 230V
LIM+: 06% (243.8V)
LIM-: 10% (207.0V)
+
-
RECORDER CONFIG
VOLTAGE REC:
V12
V32
V31
HARM. REC:Pg (ON)
Vref P-P: 400V
LIM+: 06% (424.0V)
LIM-: 10% (360.0V)
+
-
RECORDER CONFIG
VOLTAGE REC:
V1
V2
V3
V12 V32 V31
HARM. REC:Pg (ON)
Vref P-N: 230V
LIM+: 06% (243.8V)
LIM-: 10% (207.0V)
+
-
ENTER
RECORDER CONFIG
VOLTAGE HARMONICS
Thd
DC
01
02
03
04
05
06
07
08 09 10 11
12 13 14 15 16 17 18
19 20 21 22 23 24 25
26 27 28 29 30 31 32
33 34 35 36 37 38 39
40 41 42 43 44 45 46
47 48 49
+
-
Use the multifunction keys F1, F2
to position the cursor on the
desired word and use the
multifunction keys F3 / F4 to modify
the value.
Press ENTER to confirm and
proceed inside the Menu, keeping
the settings made.
Press ESC to leave the Menu
without modifying the existing
parameters.
Use the multifunction keys F1,
F2 to position the cursor on the
desired voltage harmonic and
use the multifunction keys F3 /
F4 to select / deselect (it’s
selected if highlighted in
black).
Press ENTER to confirm.
Press ESC to leave the Menu
without modifying the existing
settings.
The instrument will record the
values of the selected
harmonics corresponding to
the voltages selected in one of
the two pages of the Menu
previously illustrated.
ENTER
MENU
To Select MANUAL or AUTOMATIC
start/stop mode, place the cursor on
MANU or AUTO using the
multifunction key F1 or F2 and select
the desired mode using F3 or F4.
If you want to change Voltage Harm. Selection place the
cursor on the corresponding “Pg” symbol then Press F3
Use the multifunction keys F1, F2
to position the cursor on the
desired word and use the
multifunction keys F3 / F4 to select
/ deselect the desired parameter
(it’s selected if marked in black).
Press ENTER to confirm and leave
the Menu keeping the settings
made.
Press ESC to leave the Menu
without modifying the existing
parameters.
