8
1.3 Specifications
Product Model EZ650
Pickup Device 1/3” SONY Super HAD CCD Ⅱ
Video Format NTSC or PAL
Picture Elements 768 x 494 (NTSC)/752 x 582 (PAL)
Horizontal Resolution 560 TV Lines
Sensitivity 0.05Lux/F=1.2(AGC ON);
0.0002Lux/F=1.2 (IR off ,Sens-up 256x Max; ~8X recommened)
0 Lux (IR On)
S/N Ratio Over 52dB (AGC off)
Electronic Shutter 256x, 128x, ….1/50 (1/60) ~1/100,000
Video Output BNC 1.0V p-p 75Ω,
Gamma Correction 0.45
Lens Type DC Iris Varifocal : 6~50mm focal length
True Day & Night Yes, automatic motorized IR cut filter
Back Light Compensation OFF/BLC/HSBLC Selectable
Auto Gain Control Low/Middle/High Selectable
White Balance ATW/AWB/AWC/Manual/Indoor/Outdoor Selectable
Sync. Mode Internal/Line lock
Day & Night Auto/Color/BW/EXT
OSD menu Multiple functions
IR Emitters 42 long life LEDs
IR Configuration Split glass isolation prevents internal reflections
IR wavelength 850nm
IR LED Lifespan 20,000 hours
IR Distance 80m/261ft(AGC ON) ,100m/328ft
3D-DNR OFF/ON, adjustable level.
Digital WDR Outdoor, Indoor
Mirror Off/Mirror/V-Flip/Rotate Selectable
Digital Zoom Off/On selectable up to 32X
Motion Detection Off/On for 4 selectable zones
Privacy Mask Off/On for 8 selectable zones
RS-485 Control input for menu/zoom/focus.
Power Source 2 models: 24VAC ; 100VAC~240VAC
Power Consumption AC24V:
camera: 5W
camera+heater: 11.5W
camera + int. IR: 12.7W
camera + int. IR + heater: 19.3W
AC110~240V:
camera: 3.2W
camera+heater: 9.2W
camera + int. IR: 10.6W
camera + int. IR + heater: 16.6W
Dimensions 115mm x 275mm / 4.5” x 10.8”
Weight 2.91kg
Operating Temperature
-40°C to +50°C / -40ºF to 122 ºF
Weatherproof Ratings IP66
Heater Yes, Built-in, thermostatically controlled
Vandal resistant Yes
