23
3.2 RS485 ID & Baud Rate Setting
Note: This section is optional preserved for the people that want to change camera ID and baud rate.
In most situations, we suggest you can just use Camera ID-01 and Baud Rate-9600, Protocol-Pelco D
on keyboard, then it would work.
I. Please turn the control key selection switch at back panel to “OSD”( ).
II. Press the mini-joystick for 4 seconds until you see the following menu.
III. Turn the mini-joystick up () or down () to adjust setting, press mini-joystick to go next selection.
IV. Please wait 3 seconds after setting any item, it will automatically switch to next setting item.
V. Camera setting order:
a. Firmware version. VER_xxx- shows the current firmware version.
A B C D E F G H I J K L M
N O P Q R S T U V W X Y Z
a b c d e f g h i j k l m
n o p q r s t u v w x y z
─ · 0 1 2 3 4 5 6 7 8 9
  C L R P O S E N D
F I R M W A R E _+ V E R _ _ _
