21
3. OSD Menu & Configuration
This chapter introduces how to configure the camera OSD menu.
3.1 Control Key General Operation Guide
Please turn the control key selection switch at the back panel to “OSD” ”( ).
Use the control key to do OSD menu setting.
I. Bring Up the General OSD Menu
Simply press the mini-joystick to bring up the general OSD menu.
II. Bring up the RS485 Setting Menu
Press the mini-joystick and hold for 5 seconds to bring up the RS485 setting menu.
III. Navigate among the OSD Menu Items
Turn the mini-joystick up () or down () to move the cursor up or down.
IV. Change Modes or Setting Parameters
Turn the mini-joystick left () or right () to adjust the mode or parameter of settings.
V. Switch to Sub-menu Screens
Chapter
3
The Cursors & the mini-joystick
Mini-Joystick
UP
