System Data
36
Table 14 Liebert Challenger ITR chilled water data, 60 Hz
Capacity Data BTU/H (kW) @ 45°F (7.2°C) EWT, 10°F (5.6°C) Water Rise; Net Capacity Data
Indoor Unit
BR = Horizontal Flow BR 102C Indoor Unit BR 102C
100ºF DB, 70ºF WB (37.8ºC DB, 21.1ºC WB) 20% RH, 12°F
(6.7°C) Water Rise
Fan Data (Blower A12x9AT)**
Total BTU/H (kW) 125,000 36.6 Standard Air, CFM (CMH) 2800 (4760)
Sensible BTU/H (kW) 118,000 34.6 Standard Fan Motor, hp (kW) 1-1/2 (1.1)
Flow Rate GPM (l/s) 21.4 1.4 Opt. Fan Motor, hp (kW) 2 (1.5)
Pressure Drop ft (kPa) 25.5 76.0 Ext Static, in. WG (Pa) .3 (75)
95ºF DB, 68.3ºF WB (35ºC DB, 20.2ºC WB) 24% RH, 12°F
(6.7°C) Water Rise
Chilled Water Coil (V-Frame, at standard conditions)
Total BTU/H (kW) 113,000 33.1 Face Area, ft. 2 (m 2 ) 6.67 (.62)
Sensible BTU/H (kW) 107,000 31.4 Rows 4
Flow Rate GPM (l/s) 19.6 1.2 Face Velocity, FPM (m/s) 405 (2.1)
Pressure Drop ft (kPa) 21.7 64.7 Electric Reheat 2 Stage (Stainless Steel, Fin Tubular) - Std
90ºF DB, 66.5ºF WB (32.2ºC DB, 19.2ºC WB) 28% RH, 12°F (6.7°C)
Water Rise
Capacity, inc. motor heat, BTU/H ( element kW) 56,200 (15)
Total BTU/H (kW) 101,000 29.6 Hot Water Reheat 180°F (82.2°C) EWT, 75°F (23.9°C) EAT -
Optional (includes std air volume and opt fan motor hp) Sensible BTU/H (kW) 94,700 27.7
Flow Rate GPM (l/s) 17.4 1.1 Capacity, inc. motor heat, BTU/H (kW) 88,700 (26.0)
Pressure Drop ft (kPa) 17.4 51.9 Flow Rate, GPM (l/s) 5.0 (.32)
85ºF DB, 64.4ºF WB (29.4ºC DB, 18ºC WB) 32% RH Pressure drop, ft. (kPa) 16.9 (50.4)
Total BTU/H (kW) 91,000 26.7 Infrared Humidifier - Standard
Sensible BTU/H (kW) 85,000 24.9 Capacity, lb/hr (kg/hr) 11 (5)
Flow Rate GPM (l/s) 18.9 1.2 kW 4.8
Pressure Drop ft (kPa) 20.2 60.2 Steam Generating Humidifier - Optional
80ºF DB, 62.7ºF WB (26.7ºC DB, 17.1ºC WB) 38% RH Capacity, lb/hr (kg/hr) 11 (5)
Total BTU/H (kW) 79,000 23.1 kW 3.9
Sensible BTU/H (kW) 72,400 21.2
Filter Section - Efficiencies per ASHRAE 52.1 - Disposable
Type
Flow Rate GPM (l/s) 16.5 1.0
20% Eff. available in 2" (51mm) - Std, or Opt 4" (102mm) Depths;
other Optional 4" (102mm) Eff. are: 30%, 40-45%, 60-65%
Pressure Drop ft (kPa) 15.8 47.1
Nominal Size - in (mm)
28.5 x 29.5
(724 x 749) 80ºF DB, 66.5ºF WB (26.7ºC DB, 19.2ºC WB) 50% RH
Total BTU/H (kW) 98,200 28.8 Effective Surface Area, ft 2 (m 2 ) 24.1 (2.2)
Sensible BTU/H (kW) 71,500 20.9 Connection Sizes Challenger ITR Unit
Flow Rate GPM (l/s) 19.7 1.2 CW Supply 1-1/8 OD Cu
Pressure Drop ft (kPa) 22.1 65.9 CW Return 1-1/8 OD Cu
75ºF DB, 62.5ºF WB (23.9ºC DB, 16.9ºC WB) 50% RH Humidifier Supply 1/4 OD Cu
Total BTU/H (kW) 72,900 21.4 Condensate Drain 1/2 FPT
Sensible BTU/H (kW) 61,000 17.9 Control Valve
Flow Rate GPM (l/s) 14.7 0.9 Maximum design water pressure 150 psi (1034.3 kPa)
Pressure Drop ft (kPa) 12.8 38.1 Valve Actuator Modulating
75ºF DB, 61.1ºF WB (23.9ºC DB, 16.2ºC WB) 45% RH Sensors Proportional
Total BTU/H (kW) 68,200 20.0 Valve Body Three-Way
Sensible BTU/H (kW) 63,100 18.5 Valve Size, inches 1
Flow Rate GPM (l/s) 13.3 0.8 Cv 13.9
Pressure Drop ft (kPa) 10.6 31.6 Two-Way Valve (Optional)
72ºF DB, 60.1ºF WB (22.2ºC DB, 15.6ºC WB) 50% RH Close-Off Pressure, PSI (kPa) 70 (483)
Total BTU/H (kW) 59,900 17.6
* The net capacity data has fan motor heat factored in for all ratings and
the entering air condition of 72°F (22.2°C) and 50% RH is the standard
rating for ASHRAE 127-2001. All capacities are nominal values; actual
performance will be ±5%.
** Data rated with 2" 20% ASHRAE filter. Some options or combinations
of options may result in reduced airflow. Consult factory for
recommendations.
Sensible BTU/H (kW) 54,400 15.9
Flow Rate GPM (l/s) 12.0 0.8
Pressure Drop ft (kPa) 8.8 26.2
72ºF DB, 58.7ºF WB (22.2ºC DB, 14.8ºC WB) 45% RH
Total BTU/H (kW) 56,200 16.5
Sensible BTU/H (kW) 55,300 16.2
Flow Rate GPM (l/s) 11.1 0.7
Pressure Drop ft (kPa) 7.6 22.6
