System Data
27
Table 5 Liebert Challenger ITR air-cooled data—50Hz (continued)
System Type
Self-Contained
Split Systems
w/Outdoor Prop-Fan
Condensing Unit
w/Indoor Centrifugal
Condensing Unit
Indoor Unit BR 065A BR 059E BR 059E
Infrared Humidifier - Standard
Capacity - kg/hr (lb/hr) 5 (11) 5 (11) 5 (11)
kW 4.8 4.8 4.8
Steam Generating Humidifier - Optional
Capacity - kg/hr (lb/hr) 5 (11) 5 (11) 5 (11)
kW 3.9 3.9 3.9
Filter Section - Efficiencies per ASHRAE 52.1 - Disposable Type
20% efficiencies available in 51mm (2") - Standard, or optional 102mm (4") depths; other optional 102mm (4") efficiencies
are: 30%, 40-45%, 60-65%
Nominal Size - mm 724 x 749 724 x 749 724 x 749
Nominal Size - inches 28.5 x 29.5 28.5 x 29.5 28.5 x 29.5
Effective Surface Area - m 2 (ft 2 ) 2.2 (24.1) 2.2 (24.1) 2.2 (24.1)
Connection Sizes Challenger ITR Unit
Liquid Line 1/2 OD Cu 1/2 OD Cu 1/2 OD Cu
Hot Gas Line 7/8 OD Cu N/A N/A
Suction Line N/A 1 1/8 CD Cu 1 1/8 CD Cu
Humidifier Supply Line 1/4 OD Cu 1/4 OD Cu 1/4 OD Cu
Condensate Drain Line 1/2 FPT 1/2 FPT 1/2 FPT
Condenser Air 35°C (95°F) Ambient
Model CSF104 PFH066A_ _H MC_64A
Motor kW (hp) .56 (3/4) .56 (3/4) 1.5 (2)
Ext. Static Pa (in. WG) N/A N/A 125 (0.5)
CMH (CFM) 8750 (5150) 9854 (5800) 5947 (3500)
Liquid Line Connection 5/8 OD Cu 1/2 OD Cu* 1/2 OD Cu*
Hot Gas Connection 1-1/8 OD Cu N/A N/A
Suction Line Connection N/A 1-1/8 OD Cu* 1-1/8 OD Cu*
* The net capacity data has fan motor heat factored in for all ratings and the entering air condition of 72°F (22.2°C) and 50% RH is the
standard rating for ASHRAE 127-2001.All capacities are nominal values; actual performance will be ±5%.
** Data rated with 2" 20% ASHRAE filter. Some options or combinations of options may result in reduced airflow. Consult factory for
recommendations.
