System Data
26
Table 4
Liebert Challenger ITR air-cooled data—50 Hz
System Type
BR = Horizontal Flow
Self-Contained
Split Systems
w/Outdoor Prop-Fan
Condensing Unit
w/Indoor Centrifugal
Condensing Unit
Indoor Unit
BR 065A
BR 059E
BR 059E
Net Capacity Data
kW
BTU/H
kW
BTU/H
kW
BTU/H
37.8°C DB, 21.1°C WB (100°F DB, 70°F WB) 20% RH
Total
22.4
76,300
25.8
87,900
21.0
71,800
Sensible
22.4
76,300
25.8
87,900
21.0
71,800
Non Standard Flow Rates
2300 CFM
2100 CFM
35°C DB, 20.2°C WB (95°F DB, 68.3°F WB) 24% RH
Total
22.0
75,100
24.3
83,100
21.3
72,600
Sensible
22.0
75,100
24.3
83,100
21.3
72,600
32.2°C DB, 19.2°C WB (90°F DB, 66.5°F WB) 28% RH
Total
20.9
71,200
23.0
78,400
20.2
68,800
Sensible
20.9
71,200
23.0
78,400
20.2
68,800
29.4°C DB, 18°C WB (85°F DB, 64.4°F WB) 32% RH
Total
19.7
67,200
21.6
73,800
19.1
65,100
Sensible
19.7
67,200
21.6
73,800
19.1
65,100
26.7°C DB, 17.1°C WB (80°F DB, 62.7°F WB) 38% RH
Total
18.6
63,600
20.3
69,300
18.0
61,400
Sensible
18.6
63,600
20.3
69,300
18.0
61,400
26.7°C DB, 19.2°C WB (80°F DB, 66.5°F WB) 50% RH
Total
19.0
64,900
21.3
72,600
18.3
62,400
Sensible
15.2
51,800
16.0
54,700
14.9
50,900
23.9°C DB, 16.9°C WB (75°F DB, 62.5°F WB) 50% RH
Total
17.8
60,600
19.5
66,600
17.0
58,100
Sensible
14.7
50,300
15.5
52,800
14.4
49,300
23.9°C DB, 16.2°C WB (75°F DB, 61.1°F WB) 45% RH
Total
17.3
59,100
19.0
64,700
16.6
56,700
Sensible
15.8
54,000
16.5
56,300
15.5
53,000
22.2°C DB, 15.6°C WB (72°F DB, 60.1°F WB) 50% RH
Total
17.0
58,100
18.6
63,600
16.3
55,700
Sensible
14.4
49,300
15.1
51,700
14.2
48,300
22.2°C DB, 14.8°C WB (72°F DB, 58.7°F WB) 45% RH
Total
16.7
56,900
18.0
61,500
16.3
55,700
Sensible
15.5
52,900
16.1
54,900
16.3
55,700
Fan Data (Blower A12x9AT)**
Standard Air, CMH (CFM)
4420 (2600)
4420 (2600)
4420 (2600)
Standard Fan Motor, kW (hp)
1.1 (1-1/2)
1.1 (1-1/2)
1.1 (1-1/2)
Opt Fan Motor, kW (hp)
1.5 (2)
1.5 (2)
1.5 (2)
Ext Static, Pa (in. WG)
75 (.3)
75 (.3)
75 (.3)
Evaporator Coil (V-Frame, at Standard Conditions)
Face Area, m
2
(ft.
2
)
.62 (6.67)
.62 (6.67)
.62 (6.67)
Rows
4
4
4
Face Velocity, m/s (FPM)
1.9 (375)
1.9 (375)
1.9 (375)
Electric Reheat 2 Stage (Stainless Steel, Fin Tubular) - Standard
Capacity, element kW (inc. motor heat, BTU/H)
15 (56,200)
15 (56,200)
15 (56,200)
Hot Water Reheat 82.2°C (180°F) EWT, 23.9°C (75°F) EAT - Opt. (inc. standard air volume and optional fan motor hp)
Capacity, inc. motor heat, kW (BTU/H)
25.3 (86,200)
25.3 (86,200)
25.3 (86,200)
Flow Rate, l/s (GPM)
.32 (5.0)
.32 (5.0)
.32 (5.0)
Pressure drop, kPa (ft.)
50.4 (16.9)
50.4 (16.9)
50.4 (16.9)
* The net capacity data has fan motor heat factored in for all ratings and the entering air condition of 72°F (22.2°C) and 50% RH is the
standard rating for ASHRAE 127-2001.All capacities are nominal values; actual performance will be ±5%.
** Data rated with 2" 20% ASHRAE filter. Some options or combinations of options may result in reduced airflow. Consult factory for
recommendations.
