Precision Environmental Control for Industrial, Telecommunications, Medical and Data Processing Equipment
4
Figure 2
Unit configurations, continued
Split Systems Available
Scroll Compressor
Glycol Pump
Glycol Piping
Drycooler
Expansion Tank
V-Frame
Coil
Scroll Compressor
Remote Condenser
Water Source
(not supplied by Liebert)
Outdoor Prop-Fan
Air-Cooled Condensing Unit
Indoor Centrifugal Fan
Air-Cooled Condensing Unit
Indoor Water-Cooled
Condensing Unit
Coaxial
Condenser
Indoor Glycol-Cooled
Condensing Unit
IMAGE IS
ILLUSTRATIVE ONLY
