2. INTRODUCTION AND SPECIFICATIONS
3.1. AIR SUPPLY
Recommended hook-up procedure is shown in fig 1.
3.1.1 Ensure the sander air valve (or throttle) is in the "off" position before connecting to the air supply.
3.1.2 You will require an air pressure between 70-90psi, and an air flow according to the specification above.
3.1.3  WARNING! Ensure the air supply is clean and does not exceed 90 psi while operating the sander.
Too high an air pressure and unclean air will shorten the product life due to excessive wear, and may be
dangerous causing damage and/or personal injury.
3.1.4 Drain the air tank daily. Water in the air line will damage the sander and invalidate your warranty.
3.1.5 Clean air inlet filter weekly.
3.1.6 Line pressure should be increased to compensate for unusually long air hoses (over 8 metres).
The minimum hose diameter should be 1/4” I.D. and fittings must have the same inside dimensions.
3.1.7 Keep hose away from heat, oil and sharp edges. Check hoses for wear, and make certain that all
connections are secure.
3.2 COUPLINGS
Vibration may cause failure if a quick change coupling is connected directly to the air sander. To
overcome this, connect a leader hose to the sander. A quick change coupling may then be used to
connect the leader hose to the air line recoil hose. See fig 1 & 2 (next page).
3. PREPARING SANDER FOR USE
1.2. LEAD PAINT WARNING!
Paint once contained lead as a traditional ingredient. Contact with the dust from the removal of such
paint is toxic and must therefore be avoided. The following action must be taken before using the
sander on a surface that you suspect may contain lead paint.
1. User must determine potential hazard relating to age of paint to be removed.
(Modern paints do not have lead content).
2. DANGER! Keep all persons and pets away from the working area. The following persons are
particularly vulnerable to the effects of lead paint dust: Expectant women, babies and children.
3. We recommend personal protection by using the following safety items:
a) Paint Spray Respirator (Our ref SSP16EN)
b) PE Coated Hooded Coverall (Our ref SSP266). c) Latex Gloves (Our ref SSP24).
4. Take adequate measures to contain the paint dust, flakes and scrapings.
5. Continue to wear safety equipment as in (3) above and thoroughly clean all areas when task is
complete. Ensure paint waste is disposed of in sealed bags or containers.
fig 1
fig 2
Aluminium housing with articulated sanding arm and integral regulator. Features belt tracking control, heavy-duty
nose roller and left- or right-hand mounting for side handle. Suitable for sanding otherwise inaccessible areas
such as around door-shuts. Wide belt makes tool suitable for welding work too. Spare belts available from stock.
Specification
Belt . . . . . . . . . . . . . . . 30 x 540mm
Air Pressure . . . . . . . . . . . . . . 90psi
Air Consumption. . . . . . . . . . 20cfm
Air Inlet . . . . . . . . . . . . . . . .¼”BSP
Weight . . . . . . . . . . . . . . . . . . 2.1kg
Noise Power . . . . . . . . . . . .95dB(A)
Noise Pressure. . . . . . . . . .84dB(A)
Vibration . . . . . . . . . . . . . . 1.11m/s²
Uncertainty . . . . . . . . . . . . 0.6m/s²
