APPENDIX
DIMENSIONS
22.87 (581.0)
Unit : inch (mm)
Screw Holes for Ceiling Mount
Screws: 9-M8
Depth: 0.315 (8.0)
9.90 (251.5)
10.15 (258.0)
5.18 (131.5)
9.90 (251.5)
5.7 °
2.36 (60.0)
30.83 (783.0)
17.56 (446.0)
22.87 (581.0)
9.25 (235.0) 8.62 (219.0)
17.56 (446.0)
7.01 (178.0) 7.01 (178.0)
4.23 (107.5)
3.26 (82.8)
9.72 (247.0) 14.74 (374.5)
6.81 (173.0)
1.38 (35.0)
1.57 (40.0)
8.27 (210.0) 8.27 (210.0)
10.61 (269.5)
22.93 (582.5)
