17
BEFORE OPERATION
IMAGE BUTTON
Used to select image
level. (P31, 36)
MENU
AUTO PC ADJ. IMAGE
SELECT
ZOOM FOCUS
LENS SHIFT
ON-OFF
INPUT 1/2
INPUT 3/4
SIDE CONTROLS AND INDICATORS
Used to adjust zoom.
(P24)
INPUT 3/4 BUTTON
POWER ON–OFF BUTTON FOCUS BUTTONS
Used to select input source
either INPUT 3 or INPUT 4.
(P26, 34)
Used to adjust focus. (P24)
Used to select an item or
adjust value in MENU. It is
also used to pan image in
DIGITAL ZOOM mode.
(P33)
Used to execute item
selected. It is also used to
expand image in DIGITAL
ZOOM mode. (P33)
Used to turn a projector on
or off. (P23)
ZOOM BUTTONS
Used to select LENS
SHIFT function. (P24)
SELECT BUTTON
POINT BUTTONS
LENS SHIFT BUTTON
SIDE CONTROLS
MENU BUTTON
Used to open or close MENU
operation. (P21, 22)
INPUT 1/2 BUTTON
Used to select input source
either INPUT 1 or INPUT 2.
(P26, 34)
SIDE CONTROLS
REAR
INDICATORS
FRONT
INDICATORS
AUTO PC ADJ. BUTTON
Use to operate AUTO PC
Adjustment function. (P28)
