13
CONNECTING PROJECTOR
ANALOG RGB
R/Pr G/Y B/Pb H/HV V
CONTROL PORT
DVI
INPUT 1
R/C JACK USB
RESET
(MONO)
(MONO)
(MONO)
(MONO)
CONTROL PORT
AUDIO
CONTROL PORT
INPUT 2
INPUT 3
INPUT 4
AUDIO
AUDIO
SERIAL PORT IN
SERIAL PORT OUT
AUDIO OUT
R L
R L
R
R
L
L
The port is not functioning
in this model.
Connect audio output
from computer or video
equipment to these jacks.
(Refer to P15, 16.)
CONTROL PORT CONNECTORS
AUDIO INPUT JACKS 5 BNC INPUT JACKS
Connect component video output (Cr, Y,
Cb or Pr, Y, Pb) from video equipment to
R/Pr, G/Y and B/Pb jacks or connect
computer output [5 BNC Type (Red,
Green, Blue, Horiz. Sync and Vert.
Sync.)] from computer to R/Pr, G/Y,
B/Pb, H/HV and V jacks. (Refer to P15,
16.) Connect computer output
(Digital/Analog DVI-I type) to
this terminal.
(Refer to P15.)
HD (HDCP Compatible) signal
can also be connected.
(Refer to P16.)
DVI INPUT TERMINAL
INPUT/OUTPUT TERMINALS AND JACKS
Connect computer output
(Analog HDB 15-pin type) to
this terminal.
(Refer to P15.)
HDB 15-PIN INPUT TERMINAL
INPUT 2 INPUT 1 INPUT 1, 2, 3
INPUT 1, 2, 3
INPUT 3
