System 5-B Digital Audio Mixing System Operation Manual Channels and Strips
96
Spill Select
Spill Select allows Control Groups and Multi Format Masters to spill their slaves to a
defined area so they can be individually accessed. See Spill on page 127 for details.
1. From the Main Panel, press the Strips key.
2. Press the Spill Select key in the Strips Panel so it lights.
3. Press the Wave key on each Strip to include in the Spill area.
Fader Unity
Fader Unity allows any fader(s) to be automatically set to unity gain (0 dB).
1. From the Main Panel, press the Strips key.
2. In the Strip Config Panel Viewer, press the Fader Unity key so it lights.
3. Press the Chan Select key for each channel to set unity gain.
The fader moves to 0 dB.
You can also press that channel’s Channel Select key in the center section
Select Panel.
Figure 8-5 Center section Select Panel
4. Deselect the Fader Unity key to turn off the Fader Unity function.
Fader Meters
Fader Meters enable the Strip fader LED meters.
On: Displays the channel’s input level. This is the PFL input level, not the fader position.
Knob and Fader Text Displays
There are nine options in the Strips Config Panel to choose between values and names
on the text displays for knobs and faders:
• Knobs - momentary, show name or show value
• Fader - momentary, show name or show value
• 402 Faders - momentary, show name or show value
C5 C6 C7 C8
solo
N ON
solo
ON
solo
ON
Channel
Select key
