System 5-B Digital Audio Mixing System Operation Manual Busses and Bus Masters
88
7.2.15 Bus Master Inserts
Each Group, Main, and Aux Bus has an insert point. See Main Bus Send/Return on page
46 to learn about bus insert send and returns specified in PatchNet. Switching the insert
in/out works the same for Aux, Main, and Group busses.
1. Press the Aux Mstrs, Grp Mstrs, or Main Mstrs button to display that bus on
the Bus Master knobset.
2. Press both cfg W and X keys simultaneously.
3. Press the lower button to the left of the knob to activate that bus insert (In: but-
ton lit). Press the button again to deactivate the bus insert (Out: button not lit).
7.3 Main and Group Bus Setup
See Busses on page 48 to learn about how to configure the Main and Group Busses.
