System 5-B Digital Audio Mixing System Operation Manual GPI/O Event System
145
11.9.3 Move a Fader to Start a Cart Machine
This example demonstrates how to start a Cart machine by moving a fader above a
selected level.
1. In the Event Configuration window, under Event List, click on the
add event> field.
The Add Event dialog appears.
2. Select AND as the logical operator from the dropdown menu.
3. Under Input, click on the field.
The Add Input Event dialog appears.
4. Select Fader from the dropdown menu and click OK.
5. Configure the Input Properties to the following settings:
Channel # 2
Activation level (dB) -50
Activation Type Above
6. Under Output, click on the field.
The Add Output Event dialog appears.
7. Select GPO from the dropdown menu and click OK.
8. Configure the Output Properties to the following settings:
Output Number 1
Active State Closed
Pulse Length 10
Machine GP132 One
