System 5-B Digital Audio Mixing System Operation Manual Channels and Strips
103
Stereo Controls
There are two additional controls used for stereo channels (see Multi Format Masters
on page 126).
Figure 8-9 Stereo Controls
• Balance: Rotate the Bal knob left to hear more of the left channel; rotate right
to hear more of their right channel. Rotate left or right until the display reads
100L or 100R to hear only the left or right channel.
Left-to-mono: Press the upper key next to the Bal knob to send the left channel
equally to both the left and right sides of the stereo channel.
Swap
Aphs
Bphs
HiZ
48V
HPF
Gain
Trim
Bal
Dly
Inp
Page keys display
second page and Signal
Processing In/Out page
LTM
RTM
Dly
Dyn
Fad
Mtr
EQ
Filt
Ins
