System 5-B Digital Audio Mixing System Operation Manual GPI/O Event System
143
11.9 GPI Examples
Refer to Figure 11-1 and Figure 11-2 for these examples. The options available in the
Input and Output Properties areas are summarized in Table 11-1 and Table 11-2.
If an event consists of just one input, AND and OR deliver the same result and may be
used interchangeably.
11.9.1 Move a Fader to Turn Off the Floor Monitors
This example demonstrates how to turn off the floor monitors by moving any one of
several faders above a selected level.
1. In the Event Configuration window, under Event List, click on the
add event> field.
The Add Event dialog appears.
2. Select Or as the logical operator from the dropdown menu.
3. Under Input, click on the field.
The Add Input Event dialog appears.
4. Select Fader from the dropdown menu and click OK.
5. Configure the Input Properties to the following settings:
Channel # 1
Activation level (dB) -50
Activation Type Above
6. Repeat steps 3–5 for any additional channel faders and set the Channel # in
step 5 to the new channel number.
7. Under Output, click on the field.
The Add Output Event dialog appears.
8. Select Control Room from the dropdown menu and click OK.
9. Configure the Output Properties to the following settings:
Action Monitor A
Active State Off
