System 5-B Digital Audio Mixing System Operation Manual GPI/O Event System
148
11.9.6 Video Switcher Turns a Specific Camera and Channel Off
1. In the Event Configuration window, under Event List, click on the
add event> field.
The Add Event dialog appears.
2. Select AND as the logical operator from the dropdown menu.
3. Under Input, click on the field.
The Add Input Event dialog appears.
4. Select GPI from the dropdown menu and click OK.
5. Configure the Input Properties to the following settings:
Input # 1
Active State Off
Machine GP132 One
6. Under Output, click on the field.
The Add Output Event dialog appears.
7. Select Switch Output from the dropdown menu and click OK.
8. Configure the Output Properties area to the following settings:
Channel 3
Switch Function Channel
Activation Value Off
