CHAPTER 2: S5U1C63000H2 PACKAGE
CHAPTER
2 S5U1C63000H2 P
ACKAGE
2.1 Components
This package is in common with all models of the S1C63 Family. After unpacking the S5U1C63000H2
package, check to see that all of the following components are included.
Figure 2.1.1 shows the packing structure.
(1) S5U1C63000H2 (main unit with LCD board) ............................................ 1 unit
(2) RS232C cable (for IBM PC/AT) .................................................................... 1 cable
(3) AC adapter ....................................................................................................... 1 pcs.
(4) AC cable ........................................................................................................... 1 cable
(5) Jig for installing/dismounting board ......................................................... 2 pcs.
(6) S5U1C63000H2 Manual (S1C63 Family In-Circuit Emulator) ................ 1 copy (this manual)
(7) Flat cable with 50-pin
×
2 connectors .......................................................... 1 pair
(8) Flat cable with 34-pin connector .................................................................. 1 cable
(9) 50-pin connector for target system .............................................................. 2 pcs.
(10) 34-pin connector for target system .............................................................. 1 pcs.
(11) User registration card .................................................................................... 1 card
(12) Warranty card .................................................................................................. 1 card
(13) Precautions on using the S5U1C63000H2 .................................................. 1 sheet
Note: Following items need to be provided separately, not included in this package.
(14) S5U1C63xxxP board (included in the S5U1C63xxxP package)
(15) S5U1C63xxxP Manual (included in the S5U1C63xxxP package)
(16) S1C63 Family Debugger (included in the S1C63 Family Assembler package)
(17) S5U1C63000A Manual (included in the S1C63 Family Assembler package)
•AC adapter •Connectors
for target system •Jigs
(50-pin
Ч
2) (
Ч
2) (34-pin
×
1)
(50-pin
×
2)
•AC cable
•RS232C cable
•Flat cables
(for IBM PC/AT)
English Japanese English Japanese
•User registration card
•Warranty card
•Precautions on using the S5U1C63000H2
Registration
..............
..........
............
........ Registration
..............
..........
............
........
(34-pin
×
1)
•S5U1C63000H2 main unit
•S5U1C63000H2
Manual
1
TRGOUT
PC 0
STOPOUT TRC IN BRK IN GND
2 3 4 5 6 7 8 ICE RUN RS232C
S5U1C63000H2 EPSON
PC 1 PC 2 PC 3 PC 4 PC 5 PC 6 PC 7 PC 8 PC 9 PC 10 PC 11 PC 12 PC 13 PC 14 PC 15 SLP/HLT EMU POWER
EPSON
S5U1C63000H2 Manual
EPSON
S5U1C63000H2 Manual
Fig. 2.1.1 Packing structure
