20 EPSON S5U1C63000H2 MANUAL
(S1C63 FAMILY IN-CIRCUIT EMULATOR)
CHAPTER 7: MAINTENANCE AND WARRANTY
CHAPTER
7 M
AINTENANCE AND
W
ARRANTY
7.1 Diagnosis Test
The self diagnosis test is executed by setting SW8 of the DIP switch to OPEN and starting the debugger
after power of the S5U1C63000H2 on.
Debugger for S1C63 Ver x.xx
Copyright(C) SEIKO EPSON CORP. xxxx
Connecting with ICE .............
DIAG test, please wait 5 min. .. done
← ➀
Parameter file name : xxxxxxxx.par
Version : xx
Chip name : xxxxx
CPU version : x.x
PRC board version : x.x
LCD board version : x.x
EXT board version : x.x
ICE hardware version : x.x
ICE software version : x.x
DIAG test : OK.
Map ............................. done
Initialize ...................... done
>
When an error is detected, the error message is output at the point of ➀ instead of "done". If an error
message is output, stop using the S5U1C63000H2 because it may have a hardware failure.
This diagnosis test takes approx. 5 minuets for completion because of its precise inspection. Even in the
free run mode, it takes approx. 5 minuets for the self diagnosis test before the target program is executed.
7.2 Warranty
Please refer to the warranty card attached to the unit for the warranty details.
