EPSON
S5U1C63000H2 MANUAL
(S1C63 FAMILY IN-CIRCUIT EMULATOR)
CHAPTER 9: SPECIFICATIONS OF LCD BOARD
9.4 Product Specifications
Following shows the specifications of the LCD board components.
●
LCD board
Dimension:
254 mm (wide)
×
144.8 mm (depth)
×
13 mm (height) (including screws)
Weight:
Approx. 220 g
Power supply:
DC 5 V
±
5%, less than 1 A (supplied from S5U1C63000H2 main unit)
●
LCD cable
Onboard connector:
KEL8830E-100-170L
3M3431-5002LCSC
