Page 11
Installation
7
Connect the RS-485 communication cable to the Liebert NX as shown in Figure 7.
Figure 7
RS-485 cable connection to Liebert NX
Connect the other end of the RS-485 signal cable to the X4 slot on the monitor board. The monitor
board is inside the UPS front door.
Communication connections
on Remote Monitoring Panel board
