Connecting to COM Port for Local Management
3-10 Installation
Connecting to COM Port for Local Management
This section describes how to install a UTP straight‐through cable with RJ45 connectors and
optional adapters to connect a PC, a VT series terminal, or a modem to an Enterasys Networks
module to access Local Management. This section also provides the pinout assignments of the
adapters.
What Is Needed
The following is a list of the user‐supplied parts that may be needed depending on the connection:
• RJ45‐to‐DB9 female adapter
• UTP straight‐through cable with RJ45 connectors
• RJ45‐to‐DB25 female adapter
• RJ45‐to‐DB25 male adapter
With a UTP straight‐through cable with RJ45 connectors and RJ45‐to‐DB9 adapter, you can
connect products equipped with an RJ45 COM port to an IBM or compatible PC running a VT
series emulation software package.
With a UTP straight‐through cable and RJ45‐to‐DB25 female adapter, you can connect products
equipped with an RJ45 COM port to a VT series terminal or VT type terminals running emulation
programs for the VT series.
With a UTP straight‐through cable and an RJ45‐to‐DB25 male adapter, you can connect products
equipped with an RJ45 COM port to a Hayes compatible modem that supports 9600 baud.
Connecting to an IBM PC or Compatible Device
To connect an IBM PC or compatible device, running the VT terminal emulation, to an
Enterasys Networks module COM port (
Figure 3‐8 ), proceed as follows:
1. Connect the RJ45 connector at one end of a UTP straight‐through cable to the communications
COM port on the Enterasys Networks module. (The COM port is also known as a Console
port.)
2. Plug the RJ45 connector at the other end of the UTP straight‐through cable into an RJ45‐to‐
DB9 adapter.
3. Connect the RJ45‐to‐DB9 adapter to the communications port on the IBM PC.
4. Turn on the PC and configure your VT emulation package with the following parameters:
5. When these parameters are set, the startup screen will display. Refer to the appropriate
Enterasys Matrix DFE‐Diamond/Platinum Series Configuration Guide for further information.
Parameter Setting
Mode 7 Bit Control
Transmit Transmit=9600
Bits Parity 8 Bits, No Parity
Stop Bit 1 Stop Bit
