10 VS-616G5 Installation & Quick-Start Manual
VS-616G5 SPECIFICATIONS (continued)
575V
* HP ratings based on NEMA 4-pole motor data. However, when sizing a drive to match a motor, use output current ratings.
#
For proper operation, the motor rated current must be less than or equal to the inverter rated current.
** kVA ratings are based on 200V, 400V, and 600V inputs respectively.
Inverter Model
CIMR-G5U
VS-616G5
51P5 52P2 53P7 55P5 57P5 5011 5015 5018 5022 5030 5037 5045 5055 5075 5090 5110 5160
O
utp
ut Cha
rac
te
ris
tic
s
Nominal Motor Output (HP) *
Constant Torque 2 3 5 7.5 10 15 20 25 30 40 50 60 75 100 125 150 200
Variable Torque 3 3 5 10 10 15 20 25 30 40 50 60 75 100 150 200 200
Capacity (kVA) ** 2 3 5 7.5 10 15 20 25 30 40 50 60 75 100 125 150 200
Rated Output Current (A) #
Constant Torque (A) 3.5 4.1 6.3 9.8 12.5 17 22 27 32 41 52 62 77 99 130 172 200
Variable Torque (A) 3.9 4.6 7 11 14 19 25 30 36 46 58 69 86 111 145 192 224
Maximum Voltage 3-Phase, 500/575/600V(Proportional to input voltage)
Rated Output Frequency Up to 400 Hz available
Overload Capacity
150% Rated Current / 1 minute (CT rating)
120% Rated Current / 1 minute (VT rating)
Po
wer
Su
ppl
y Input Current (A) 4.3 5.1 7.7 12.1 15.4 21 28 33 40 51 64 76 95 122 160 211 246
Rated Voltage & Frequency 3-Phase, 500 to 600V, 50/60Hz
Voltage Fluctuation +10%, -15%
Frequency Fluctuation ±5%
Chapter 1 - Receiving & Installation
Specifications
