Grid configurations TN-C, TN-S, TN-C-S, TT (when V
N_PE
< 20 V)
National standards and approvals,
as per 4/2015* AS 4777, ANRE 30, BDEW 2008,
C10/11:2012, CE, CEI 0-16, CEI 0-21,
IEC 62109-1, EN 50438, G59/3,
IEC 61727/MEA, IEC 61727/PEA,
IEC 62109-2, IEC 62116, IEC 60068-2-x,
NBR 16149, NEN EN 50438, MEA 2013,
NRS 097-2-1, PEA 2013, PPC, RD 661/2007,
RD 1699/RD 413, Res. no.7:2013, SI 4777,
VDE-AR-N4105, VDE 0126-1-1, VFR 2014,
UTE C15-712-1
* EN 50438: Does not apply to all country standard deviations of EN 50438
IEC 62109-2: In order to meet the requirements of this standard, the inverter must either be equipped
with a multifunction relay used as a fault indicator contact or there must be a connection to Sunny Portal
with the fault alarm in Sunny Portal activated.
NRS 97-1-2: This standard requires a separate label attached to the AC distribution board which
indicates the AC-side disconnection of the inverter in case of a grid failure (for further details, see NRS
97-1-2, Sect. 4.2.7.1 and 4.2.7.2).
RD 1699 and RD 661/2007: Contact the Service for restrictions in specific regions.
Climatic Conditions
Installation in accordance with IEC 60721-3-4, Class 4K4H
Extended temperature range -25°C to +60°C
Extended humidity range 0% to 100%
Threshold for relative humidity, non-condensing 100%
Extended air pressure range 79.5 kPa to 106 kPa
Transport in accordance with IEC 60721-3-4, Class 2K3
Temperature range -25°C to +70°C
Equipment
DC connection SUNCLIX DC connector
AC connection Spring-cage terminal
Speedwire/Webconnect data module As standard
RS485, galvanically isolated Optional
Multifunction relay Optional
SMA Power Control Module Optional
Surge arrester type II Optional
10 Technical Data SMA Solar Technology AG
Operating Manual STP20-25TL-BE-en-12 46
