Tables and overviews
18.3 Technical Information
18
576
TNC 620 | User's Manual
HEIDENHAIN Conversational Programming | 3/2014
Accessories
■ One HR 410 portable handwheel, or
■ One HR 550 FS portable wireless handwheel with display or
■ One HR 520 portable handwheel with display, or
■ One HR 420 portable handwheel with display or
Electronic Handwheels
■ One HR 130 panel-mounted handwheel, or
■ Up to three HR 150 panel-mounted handwheels via HRA 110
handwheel adapter
■ TS 220: triggering 3-D touch probe with cable connection, or
■ TS 440: 3-D touch trigger probe with infrared transmission
■ TS 444: Battery-free 3-D touch trigger probe with infrared transmission
■ TS 640: 3-D touch trigger probe with infrared transmission
■ TS 740: High-precision 3-D touch trigger probe with infrared
transmission
Touch probes
■ TT 140: 3-D touch trigger probe for tool measurement
■ TT 449: 3-D touch trigger probe for tool measurement with infrared
transmission
Hardware, options
■ 1st additional axis for 4 axes plus spindle
■ 2nd additional axis for 5 axes plus spindle
Software option 1 (option number 08)
Rotary table machining ■ Programming of cylindrical contours as if in two axes
■ Feed rate in distance per minute
Coordinate transformation ■ Working plane, tilting the ...
Interpolation ■ Circle in 3 axes with tilted working plane (spacial arc)
Software option 2 (option number 09)
■ Motion control with minimum jerk
■ 3-D tool compensation through surface normal vectors
■ Using the electronic handwheel to change the angle of the swivel head
during program run without affecting the position of the tool point.
(TCPM = T ool C enter P oint M anagement)
3-D machining
■ Keeping the tool normal to the contour
■ Tool radius compensation perpendicular to traversing and tool direction
Interpolation ■ Linear in 5 axes (subject to export permit)
