Programming: Programming contours
6.4 Path contours - Cartesian coordinates
6
200
TNC 620 | User's Manual
HEIDENHAIN Conversational Programming | 3/2014
6.4 Path contours - Cartesian coordinates
Overview of path functions
Function Path function key Tool movement Required input Page
Straight line L Straight line Coordinates of the end
point of the straight line
201
Chamfer: CHF Chamfer between two
straight lines
Chamfer side length 202
Circle center CC None Coordinates of the
circle center or pole
204
Circular arc C Circular arc around a
circle center CC to an
arc end point
Coordinates of the arc
end point, direction of
rotation
205
Circular arc CR Circular arc with a
certain radius
Coordinates of the arc
end point, arc radius,
direction of rotation
206
Kreisbogen CT Circular arc with
tangential connection
to the preceding and
subsequent contour
elements
Coordinates of the arc
end point
208
Corner rounding
RND
Circular arc with
tangential connection
to the preceding and
subsequent contour
elements
Rounding radius R 203
FK free contour
programming
Straight line or
circular path with any
connection to the
preceding contour
element
See "Path contours
– FK free contour
programming
(Advanced
Programming Features
software option)",
page 219
223
