Programming: Pallet editor

13.1 Pallet Management (software option)

432

TNC 620 | User's Manual

HEIDENHAIN Conversational Programming | 3/2014

Select pallet table

Call the file manager in the Programming and Editing or Program
Run mode: Press the

PGM MGT key

Display all type .P files: Press the

SELECT TYPE and SHOW ALL

soft keys
Select a pallet table with the arrow keys, or enter a new file

name to create a new table
Confirm your entry with the

ENT key

Exiting the pallet file

Call the file manager: Press the

PGM MGT key

Select a different type of file: Press the

SELECT TYPE soft key

and the soft key for the desired file type, for example

SHOW.H

Select the desired file

Run pallet file

MP7683 defines whether the pallet table is to be

executed blockwise or continuously.
Use the screen layout button to switch between

table view and form view.

Select the file manager in the Program Run, Full Sequence or
Program Run, Single Block operating modes: Press the

PGM

MGT key
Display all type .P files: Press the

SELECT TYPE and SHOW P.

soft keys
Select the pallet table with the arrow keys and confirm with

ENT

Execute the pallet table: Press the NC start key
