Manual operation and setup
14.6 Using 3-D touch probes (Touch Probe Function software option)
14
464
TNC 620 | User's Manual
HEIDENHAIN Conversational Programming | 3/2014
14.6 Using 3-D touch probes (Touch Probe
Function software option)
Overview
The following touch probe cycles are available in the Manual
Operation mode:
HEIDENHAIN only gives warranty for the function of
the probing cycles if HEIDENHAIN touch probes are
used.
The TNC must be specially prepared by the machine
tool builder for the use of a 3-D touch probe. Refer to
your machine manual.
Function Soft key Page
Calibrating the effective length 472
Calibrating the effective radius 473
Measuring a basic rotation using a
line
477
Setting a datum in any axis 479
Setting a corner as datum 480
Setting a circle center as datum 482
Setting the centerline as datum 484
Touch probe system data
management
See
User’s
Manual
for Cycles
For more information about the touch probe table,
refer to the User’s Manual for Cycle Programming.
