Linear Encoders
Linear Encoders
Setting the display step with linear encoders
The display step depends on the:
• Subdivision (P32)
• Counting step (P33)
• Decimal places (P38)
Example
Linear encoder with signal period 10 µm
Required display step .............. 0.000 5 mm
Subdivision (P32) ..................... 20
Counting step (P33) ................. 5
Decimal places (P38) ............... 4
The tables on this page and the next pages will help
you selecting your parameters.
Display step, signal period and subdivision for
linear encoders
Signal period [µm]
Display step 2 4 10 20 40 100 200 12 800
[mm] [inch] P32: Subdivision
0,000 005 0,000 000 2 400 – – – – – – –
0.000 01 0.000 000 5 200 – – – – – – –
0.000 02 0.000 001 100 – – – – – – –
0.000 05 0.000 002 40 80 – – – – – –
0.000 1 0.000 005 20 40 100 200 – – – –
0.000 2 0.000 01 10 20 50 100 – – – –
0.000 5 0.000 02 4 8 20 40 80 – – –
0.001 0.000 05 2 4 10 20 40 100 – –
0.002 0.000 1 1 2 5 10 20 50 100 –
0.005 0.000 2 0.4 0.8 2 4 8 20 40 –
0.01 0.000 5 0.2 0.4 1 2 4 10 20 –
0.02 0.001 – – 0.5 1 2 5 10 –
0.05 0.002 – – 0.2 0.4 0.8 2 4 256
0.1 0.005 – – 0.1 0.2 0.4 1 2 128
0.2 0.01 – – – – – – – 64
