32 ©2001 XSWITCH Installation and Operations Manual
$SSHQGL[ $ 5HPRWH $FWLYDWLRQ
Definitions:
Screen Data - The screen data is too large for the normal parkervision protocol. It is sent without any pro-
tocol wrapping. Immediately after sending this command the following packet will be returned...
[ Width ] [ Height ] [ Bitmap Data ]
Width = The LCD width in pixels ( 120 )
Height = The LCD height in pixels ( 80 )
Bitmap Data = Monochrome bitmap data of ( Width * Height ) / 8 in length. (1200 bytes)
_____________________________________________________________________________________
Examples: Reply
Get Screen Capture
2 [ 120 ] [ 80 ] [ .....1200 Bytes ..... ]
* The XSWITCH will pause briefly while sending the data.
** This command should not be used during normal operations.
