Installation Procedures
20 RS-422 Interface Board Installation
3. Carefully remove the RS-422 Interface board by grasping the edge of the
circuit board above the EISA connector and pulling up.
NOTE:
- Do not grasp or pull on the rear-panel connectors when removing or
installing the circuit boards.
- It may be necessary to loosen the screw mounting the Genlock board in
slot J16.
- Some systems have full height Genlock boards which may have to be
removed to allow a firm grasp of the RS-422 board. Refer to the
following procedure.
Removing the Genlock Board For RS-422 Board Removal
Some Profile systems have full height Genlock boards in slot J16 which must be
removed to allow a firm grasp of the RS-422 board.
To remove the Genlock board from slot J16 for RS-422 board removal:
1. Remove all external and internal cables from the Genlock board. Be sure to
make a cabling diagram that you can use later to reinstall the cables.
2. Use the Torx tool with the T15 tip to remove the screws which secure the
Genlock board to the rear panel (see
Ê and Ë in Figure 5 as an example).
3. Use the extraction lever on the front of the board and the extraction ring at
the back of the board to lift the circuit board free of the connectors on the
motherboard.
4. Carefully remove the RS-422 Interface board by grasping the edge of the
circuit board above the motherboard connector and pulling up.
