Kayak HD — Installation and Service Manual 119
Install Menus Reference
Hints for ESAM-2 and Yamaha DM-1000 Audio Switcher
If a Yamaha DM-1000 audio switcher is controlled via the ESAM-2 protocol
please note the following behavior:
The Yamaha DM-1000 has a different input number as defined in the
ESAM-2 protocol
Table 8.
Select Response
Video Input 1 Audio Fader 8
Video Input 2 Audio Fader 7
Video Input 3 Audio Fader 6
Video Input 4 Audio Fader 5
Video Input 5 Audio Fader 4
Video Input 6 Audio Fader 3
Video Input 7 Audio Fader 2
Video Input 8 Audio Fader 1
Video Input 9 Audio Fader 16
Video Input 10 Audio Fader 15
