58 K2 Dyno Replay Controller Service Manual June 16, 2009
Chapter 4 Removing and replacing FRUs
Plastic cover removal
To remove the plastic cover, first remove the jog knob, T-bar lever handle, and top,
then work on the top unit separately, as illustrated.
Remove 7 s crew s 1
Remove pla s tic cover
from top
2
