Depending on the channel setup (architecture) the resulting video signal is avail-
able on the following DVx outputs:

Channel 1:

Single:

DVX1 (video on superblack)

Pair 1 / 2:

Combiner output video DVX 1, combiner output

key DVX 2.

Triple:

Combiner output video DVX 1, combiner output
key DVX 2.

Quadruple:

Combiner output video DVX 1, combiner output
key DVX 2.

Channel 2:

Single:

DVX2 (video on superblack)

Pair 1 / 2:

Combiner output video DVX 1, combiner output
key DVX 2.

Triple:

Combiner output video DVX 1, combiner output
key DVX 2.

Quadruple:

Combiner output video DVX 1, combiner output
key DVX 2.

Channel 3:

Single:

DVX3 (video on superblack)

Pair 3 / 4:

Combiner output video DVX 3, combiner output

key DVX 4.

Triple:

Combiner output video DVX 1, combiner output
key DVX 2.

Quadruple:

Combiner output video DVX 1, combiner output
key DVX 2.

Channel 4:

Single:

DVX4 (video on superblack)

Pair 3 / 4:

Combiner output video DVX 3, combiner output
key DVX 4

Triple:

not possible on channel 4

Quadruple:

Combiner output video DVX 1, combiner output
key DVX 2

The cube–builder always uses channels 1–3, that means, when you want to build
a cube you need a triple – or a quadruple if you want to used a cube (channel 1–3)
and channel 4 as an independent channel, all on one combiner output.

Depending on your channel settings you can run up to 4 DVx effects simulta-
neously.
