48
Operation
Operation of the CopperHead 3430AP Transceiver System
Push and hold the Display Select Button and the system
advances to Diagnostics mode – DIAG LED is lit.
You main join the diagnostic display cycle at any sub-mode – the
diagnostics cycle through Temperature, Power, Revision and
Camera Status
DIAGNOSTIC MODE Temperature (TEMP)
DIAG When first entering the Diagnostic mode the DIAG display
mode indicator LED will blink – The first sub‐mode is TEMP
(Temperature). The Digital Display Characters will glow Green
when the temperature is normal and Red when outside of nor‐
mal range.
DIAG/TEMP DIS The Display Power Supply temperature will be displayed
DIAG/TEMP TEMP Indicates the display is in the TEMP sub‐mode
DIAG/TEMP 39c Temperature display in Centigrade for Power Supply circuit
board (representative temperature – your unit may vary)
DIAG/TEMP MAIN The Base Station main circuit board temperature will be dis‐
played
DIAG/TEMP TEMP Repeats that the display is in the TEMP sub‐mode
DIAG/TEMP 33c Temperature display in Centigrade for Base Station circuit
board
DIAG/TEMP PS The Power Supply (PS) temperature will be displayed
DIAG/TEMP TEMP Repeats that the display is in the TEMP sub‐mode
DIAG/TEMP 30c Temperature display in Centigrade for Power Supply circuit
board
This temperature display cycle repeats until the Display Mode
Selector is pushed
DIAGNOSTIC MODE Power Supply Voltage Status (POWER)
DIAG/POWER A quick push of the Display Mode Selector advances to the Power
(POWR) diagnostic sub-mode. Digital Display Characters are Green
when all power levels are normal and Red when any power level is
outside normal level
DIAG/POWER AUD Indicates that the Audio controller board is being measured
DIAG/POWER POWR Indicates the display is in the POWER sub-mode
DIAG/POWER OK Indicates that the item is in an OK State
DIAG/POWER VBS Indicates that the VBS (analog Video) controller board is being mea-
sured
DIAG/POWER POWR Indicates the display is in the POWER sub-mode
DIAG/POWER OK Indicates that the item is in an OK State
DIAG/POWER DISP Indicates that the LED Display controller board is being measured
DIAG/POWER POWR Indicates the display is in the POWER sub-mode
DIAG/POWER OK Indicates that the item is in an OK State
Display Mode
Typical
Readout Base Station Digital Display Activity Explanation
