31
CopperHead 3430AP
User Manual
Base Station but not used in the camera configuration are noted as Not Available (NA). Key
numbers refer to the diagram above.
1 & 21Power In
Connect a standard 3 conductor AC Cable (IECPlug) 100-240V 50/60 Hz standard or a 12V
DC ADAP power source (4 Pin)
4 Fiber Connector
(This connector can be mounted on the Base Station Front Panel – see page 15)
Connect the ST fiber connectors from the HDX-Plus power saupply.
5 Sync In/Loop
BNC Connector – standard Genlock/Sync/Tri-Level sync signal. The loop-through is self-ter-
minating.
6 Prompter In
N/A in 3430AP configuration
7 Time Code In
BNC Connector – Standard time code signal sent to camera – typically originating from a
“house” time code generator feed available at the Base Station. On remote productions the
primary camera may be used to originate the system time code feed (signal would return to
base station via connector 8 and then be distributed to other cameras through the associ-
ated Copperhead Base Stations
8 Time Code Out
N/A in 3430AP configuration.
9 Multi‐Pin Connector A
DB9 – 9 pin serial connector connected to an optional Camera Remote Control Panel
Power to the Base Unit (and the Camera Unit & Camera) must be turned
off when connecting the Camera Remote Control Panel – connecting with
the power on can seriously damage your equipment.
10 Multi‐Pin Connector B
DB15 – 15 pin serial connector connected to a breakout of Tally and GPI signal connectors.
Typically this connector will be connected to the Camera Tally system originating at the
Production Switcher or the Tally Management system used in your production environ-
ment. Additional custom GPI contact closures can be configured.
See page 66 for a typical configuration.
11 Ethernet Connector – 10Bt/100Bt capable
Designed to carry IP traffic data between the Base Station and the Camera Unit. A laptop
PC or other device such as a Wireless Access Point can be connected to the Production Envi-
